Bilateral Multi-Hole Frame Diagonal Port Vertical Fin Black Coated Universal Refrigeration Condenser
1. Product Overview
This square black coated all-aluminum condenser adopts bilateral perforated fixing frames, with refrigerant inlet and outlet arranged diagonally on upper and lower headers. Two integrated L-shaped support feet are welded on the bottom for stable vertical installation. Vertical dense louver fins and internal microchannels are formed by integral vacuum brazing, compatible with R134a, R744 and other common refrigerants. It efficiently condenses high-pressure gaseous refrigerant, and the matte black anti-rust coating adapts to dusty, rainy and salt-fog working scenarios widely. Core size, pipe diameter and hole positions support customized processing for multiple industries.
2. Core Feature Highlights
· Diagonal refrigerant port layout lengthens the internal flow path of the medium, improves heat exchange efficiency within limited overall volume and enhances full condensation effect.
· Even multi-point holes on bilateral frames realize uniform stress distribution, effectively resisting loose assembly and pipeline rupture caused by long-term vibration of equipment and vehicles.
· Bottom double integrated support feet buffer vibration transmission between the condenser and mounting base, protecting internal brazed welding joints from fatigue damage.
· Vertical micro-louver fin structure destroys air laminar flow, strengthens forced convection heat transfer, matches various fan configurations to achieve high condensation efficiency with low wind resistance loss.
· High-adhesion black electrostatic coating isolates the aluminum substrate from corrosion media such as rainwater and salt mist, preventing fin clogging and refrigerant leakage failures in long-term service.
3. Standard Technical Parameters
|
Item
|
Specification
|
|
Product Model
|
Universal Refrigeration Condenser with Bilateral Multi-Hole Frame, Vertical Fin & Black Spraying
|
|
Raw Material
|
3003 pressure and vibration resistant aluminum alloy + high-temperature matte black electrostatic coating, seamless refrigerant pipes
|
|
Internal Pipeline Pressure Test
|
2.0–3.2 MPa air tightness test for every finished product
|
|
Fin Form & Density
|
Vertical micro louver fin, adjustable within 24–42 FPI
|
|
Max Allowable Working Temperature
|
≤110℃
|
|
Production Process
|
Fin automatic arrangement & stacking, integral vacuum brazing for microchannels, header integral welding, overall high-temperature spray curing
|
|
Applicable Medium
|
R134a, R744 and other mainstream refrigerants for vehicle air conditioning, industrial refrigeration units
|
4. Applicable Working Environment
|
Item
|
Requirement Standard
|
|
Ambient Temperature Range
|
-45℃ ~ +78℃
|
|
Relative Humidity
|
3%–98%, applicable to highway vehicles, industrial workshops, coastal facilities, construction machinery and other environments with dust, water splash and salt mist
|
|
Installation Position
|
Vertical fixed installation at air intake channels of vehicle cabins, industrial refrigeration cabinets and hydraulic cooling systems
|
|
Working Condition
|
Long-term continuous operation, frequent pressure fluctuation of refrigerant pipelines, persistent low-frequency mechanical vibration
|
|
Environmental Resistance
|
Wear-resistant & anti-corrosion coating; fin gaps are easy to clean with compressed air, no chemical reaction with conventional refrigerants
|
5. Product Competitive Advantages
· Material Advantage: Thickened aluminum frame and microchannel structure deliver outstanding pressure resistance and shock resistance. The anti-corrosion coating greatly extends service life in harsh working conditions including coastal areas and snow melting road surfaces.
· Process Advantage: Integral vacuum brazing eliminates tiny pipeline leakage points. Each unit passes strict high-pressure air tightness inspection before delivery to thoroughly solve refrigerant leakage risks.
· Layout Advantage: Dual positioning structure of bilateral porous frame plus bottom support feet features strong universal interchangeability. It can replace original condensers of most vehicles and industrial equipment without bracket modification.
· Quality Control: Every condenser undergoes pipeline pressure sealing test. Frame verticality, pipe concentricity and coating compactness are inspected item by item to guarantee stable batch product quality.
· Customization Advantage: Fin density, pipe caliber, mounting hole spacing and overall dimensions can be modified according to customer drawings. Factory direct bulk supply with complete specifications and formal invoices, suitable for OEM matching and bulk procurement for automobile, industrial refrigeration, engineering machinery industries.
6. Target Market & Customer Groups
Main sales regions: Domestic automobile manufacturers, industrial refrigeration equipment factories, construction machinery supporting enterprises, refrigeration component wholesalers; spare parts merchants in Southeast Asia, the Middle East and other overseas regions. Core customers: Vehicle air-conditioning manufacturers, industrial chiller manufacturers, engineering machinery cooling system supporting factories, aftermarket refrigeration accessory suppliers.
