Upper Multi Port Central Bracket Aluminum Air Compressor Heat Exchanger Plate Fin Cooler

This square all-aluminum cooling core is specifically designed for multi-circuit integrated screw air compressors. It features a central square mounting seat at the top frame with four red-capped fluid pipe ports distributed on top and bottom sides. Dense vertical serrated turbulence fins are formed by integral vacuum brazing, with independent oil and gas separation runners built inside to enable simultaneous cooling of lubricating oil and compressed air.

• Top Central Integrated Square Bracket - Reserved for sensor and valve installation to simplify compressor internal accessory layout
• Top & Bottom Dispersed Four Fluid Ports - Enable multi-circuit medium split flow without pipeline winding and interference
• Four-Corner Independent Small Mount Lugs - Multi-point stress dispersion to resist long-term unit running vibration
• Vertical Serrated Turbulent Fin Structure - Disrupts boundary airflow to improve heat exchange efficiency under sustained high temperature load
• Isolated Oil-Gas Separate Flow Channels - Completely blocks medium mixing and prevents compressor oil emulsification failure

• Material: High-rigidity thickened aluminum frame and central bracket, strong impact resistance to adapt complex internal layout of integrated compressor units
• Craftsmanship: One-time integral vacuum brazing molding eliminates hidden leakage risks of split welded runners, reducing compressor after-sales maintenance frequency
• Performance: Central top bracket reserved installation position saves independent valve mounting space inside the compressor, optimizing overall cabinet layout compactness
• Quality Control: Separate hydraulic leak test for each medium runner, flatness calibration of central bracket and all mounting lugs before factory delivery
• Global Applicability: Customizable port quantity, position and central bracket size, meeting personalized multi-circuit cooling supporting demands of integrated screw compressor OEM manufacturers worldwide

Main sales regions include Southeast Asia, Europe, North America, Middle East and domestic integrated air compressor manufacturers. Core customers are multi-circuit screw air compressor complete machine factories, industrial air station supporting equipment suppliers, pneumatic system integrators and cross-border compressor aftermarket spare parts wholesalers.
